Remanufactured 6R80 Transmissions: Specs & Updates

To get an estimate on a rebuilt 6R80, click Get a Free Estimate.

Need a replacement transmission? Get an estimate for replacement transmissions and local installation. Look up your transmission model by vehicle make and model.

What Transmission Do I Have?

Replacement 6R80 Transmission Prices:

TransmissionStreet Smart Transmission
6R602559
6R802559

More information on 6R80 Valve Bodies and TCM’s

6R80 Applications and Compatibility:

Model
Ford Expedition
Ford Explorer
Ford F150
Ford Mustang
Ford Ranger
Lincoln Navigator

The Ford 6R80 transmission first saw production in 2007 models. The transmission fits both two-and all-wheel-drive vehicles.

The 6R80 is a six-speed automatic transmission for longitudinal engine placement in rear-wheel drive vehicles. It is based on the ZF 6HP26 transmission and is built under license by the Ford Motor Company at its Livonia Transmission plant in Livonia, Michigan.

6R80 Transmission DTCs

Trouble CodeDescription
P0701Transmission Control System Range/Performance
P0703Torque Converter/Brake Switch B Circuit
P0705Transmission Range Sensor Circuit Malfunction (PRNDL Input)
P0707Transmission Range Sensor Circuit Low Input
P0708Transmission Range Sensor Circuit High Input
P0710Transmission Fluid Temperature Sensor Circuit
P0711Transmission Fluid Temperature Sensor Circuit Range/Performance
P0712Transmission Fluid Temperature Sensor Circuit Low Input
P0713Transmission Fluid Temperature Sensor Circuit High Input
P0714Transmission Fluid Temperature Sensor Circuit Intermittent P0715
P0715Input/Turbine Speed Sensor Circuit
P0716Input/Turbine Speed Sensor Circuit Range/Performance
P0717Input/Turbine Speed Sensor Circuit No Signal
P0718Input/Turbine Speed Sensor Circuit Intermittent
P0720Output Speed Sensor Circuit
P0721Output Speed Sensor Circuit Range/Performance
P0723Output Speed Sensor Circuit Intermittent
P0729Gear 6 Incorrect Ratio
P0730Incorrect Gear Ratio
P0731Gear 1 Incorrect Ratio
P0732Gear 2 Incorrect Ratio
P0734Gear 4 Incorrect Ratio
P0735Gear 5 Incorrect Ratio
P0740Torque Converter Clutch Circuit Malfunction
P0741Torque Converter Clutch Circuit
P0742Torque Converter Clutch Circuit Stuck On
P0744Torque Converter Clutch Circuit Intermittent
P0748Pressure Control Solenoid 'A' Electrical
P0750Shift Solenoid 'A'
P0753Shift Solenoid 'A' Electrical
P0755Shift Solenoid 'B'
P0758Shift Solenoid 'B' Electrical
P0767Shift Solenoid 'D' Stuck On
P0780Shift Malfunction
P07811-2 Shift
P07822-3 Shift
P07833-4 Shift
P07844-5 Shift
P0817Transmission Fluid Pressure Manual Valve Position Switch Reverse with Drive Ratio
P0817Starter Disable Circuit
P08295-6 Shift
P0840Transmission Fluid Pressure Sensor/Switch “A”
P0960Pressure Control Solenoid “A” Control Circuit/Open
P0961Pressure Control Solenoid “A” Control Circuit Range/Performance
P0962Pressure Control Solenoid “A” Control Circuit Low
P0963Pressure Control Solenoid “A” Control Circuit High
P0973Shift Solenoid “A” Control Circuit Low
P0976Shift Solenoid “B” Control Circuit Low
P0977Shift Solenoid “B” Control Circuit High
P0979Shift Solenoid “C” Control Circuit Low
P0980Shift Solenoid “C” Control Circuit High
P0982Shift Solenoid “D” Control Circuit Low
P0983Shift Solenoid “D” Control Circuit High
P0984Shift Solenoid “E” Control Circuit Range/Performance

6R80 Recalls

Recall ID 12C23-S1 – Ford 6R80 Transmission

– Summary
In May 2012, the Ford Motor Company issued a compliance recall on the following vehicles equipped with the 6R80 transmission:

2011 – 2013 Ford F150
2011 – 2013 Ford Expedition
2011 – 2013 Ford Mustang
2011 – 2013 Lincoln Navigator

– Consequence
It seems that a faulty 6R80 transmission range sensor / TRS can cause a number of transmission problems when the shifter is placed in the Reverse position. The symptoms include failure to engage reverse gear, the electronic PRNDL indicator will not display reverse (if equipped), the backup lamps will not function, and intermittent rear video camera operation (if equipped).

– Remedy
Replace the 6R80 transmission lead frame (which includes the TRS sensor). Owners may contact Ford at 1-866-436-7332 or NHTSA at 1-888-327-4236

6R80 Technical Service Bulletins | TSBs

TSB 10-18-1 – Delayed forward/reverse engagement after cold starts – 6R80 transmission
2007 – 2010 Ford Expedition – 2009 – 2010 Ford F150 – 2009 – 2010 Lincoln Navigator
Problem – Some vehicles equipped with the 5.4L engine and the 6R75 or 6R80 transmission may experience delayed forward and/or reverse engagement after a cold start or in cold climates. The P0741, P0731 and/or P0735 DTC’s may also be present.
Solution – A new front pump adapter seal and separator plate will need to be installed. The main oil pressure regulator valve and its bore may also need to be cleaned.

TSB 11-8-4 – Fluid leak from bell housing – 6R80 transmission
2011 Ford Expedition – 2011 Ford F150 – 2012 Ford Mustang – 2011 Lincoln Navigator
Problem – Some vehicles built between 4/15/2011-6/8/2011 may experience a transmission fluid leak coming from the bell housing area.
Solution – Install updated transmission pump assembly

TSB 14-0217 – Delayed engagement park forward or reverse
2011 – 2014 Ford Expedition – 2011 – 2014 Ford F150 – 2011 – 2014 Ford Mustang – 2011 – 2014 Lincoln Navigator
Problem – Some vehicles may experience a noticeable delay when trying to engage a forward or reverse gear from Park. This can happen with the vehicle is cold (i.e. has not been driven for several hours).
Solution – Install updated 6R80 transmission pump

Common Problems with the 6R80

Slipping, Erratic Shifting, Harsh Forward or Reverse Gear Engagement: Some of the most common 6R80 transmission problems are slipping between gears, erratic up or down shifts, or a hard slam when the 6R80 transmission engages Drive or Reverse. There are a number of design flaws in this transmission, and any one of them could be causing these symptoms.

Another common problem is overheating. This happens when the moving parts inside the transmission are creating more friction heat than the ATF can remove. The most common cause of this condition is towing heavy loads, driving in stop/go traffic, or on mountain roads where the transmission has to shift a lot.

Updates to Remanufactured 6R80 Transmissions

    • Remanufactured pump, with new line bore bushings to eliminate leaks and provide superior flow and durability.
    • Remanufactured valve body, with complete system correction and recalibration kit, improves pressure control and shift quality.
    • Remanufactured and improved torque converter tested for leaks, concentricity, and balance. Upgrades exceed OE requirements and eliminate the possibilities of front seal leaks, premature bushing wear, and vibration.
    • All new, bushings installed in key locations to improve internal fluid flow control and fluid pressures.
    • Complete system correction and recalibration kit installed to address several OE flaws. Modifications include updates to servos, the PR system, and valve body accumulators.
    • Heavy-duty recalibration kit installed to reduce slippage and increase durability.
    • Complete road simulation using a dynamometer testing program called C.A.R.S. (Computer Aided Road Simulation). Every transmission is cold and hot tested before shipment.

How to Buy a Remanufactured 6R80 Transmission

1) Buying Locally

When you go to your local repair shop, they’ll order a remanufactured 6R80 transmission, then mark up the price. So at the end of the day, you’ll be paying 15% to 30% more than the actual cost of the unit.

2) Buying Online

Buying a reman transmission through a company like Street Smart Transmission will save you a considerable amount of money because you pay the wholesale price (avoiding a repair shop’s 15% to 30% markup), they’ll ship the unit to the shop of your choice free of charge, and returning your old transmission is free as well. Then all you have to pay for is the labor to install the unit (usually $400 to $800), and you’re on your way.

How Does it Work?

To order a remanufactured 6R80 transmission from a company like Street Smart Transmission, all you need to do is provide your vehicle’s VIN number, the mileage, and the address of the repair shop that you want it shipped to.

Financing

Replacing a transmission can be expensive, so Street Smart Transmission offers financing through PayPal Credit. Depending on your credit, you’ll be able to order a new transmission, get back on the road, then pay for it over time. You may have to pay labor charges for the installation up front, but you won’t have to shell out for the transmission all at once.

Shipping Charge/Location

When it comes to shipping, a transmission is quite heavy. So you’re going to pay quite a bit of money, unless the reman transmission company offers free shipping. Street Smart offers free shipping to a business address, which is usually the repair shop that you’ve chosen to install the unit.

What is a Core Charge (Core Deposit)?

Every remanufactured transmission originally came from somebody else’s car. Therefore, they need your broken transmission in order to refurbish it for another customer.

Your old/damaged transmission is called a “core”, and many companies will collect a core charge (usually $500 to $1500), which will be refunded once they receive your old transmission. (Street Smart does not charge an up-front core charge.) Make sure to ask any company for their core return policy, so you’ll know what to expect.

Easy Core Return

Our Recommendation

We recommend Street Smart Transmission. We have found Street Smart to be of the highest quality. Their transmissions carry a 3 year / unlimited miles warranty that covers both parts and labor. Their warranty is nationwide and attached to the VIN so it is transferable with ownership if you decide to sell the vehicle. It also covers both parts and labor for the installation of the replacement transmission.

Watch the Remanufacturing Process

How it Works

steps

Finding a Shop to Install the Remanufactured Transmission

If your transmission has failed, you’re going to need a skilled mechanic to replace it. You can find a shop to install your transmission using our shop locator map.

For warranty purposes, you need to find a reliable repair shop. That way, if the replacement transmission doesn’t work properly, the warranty will cover it.

Ready to Replace Your 6R80 Transmission?

Click Get a Free Estimate for an unbeatable price on a replacement remanufactured transmission.
