Chrysler 300M / 300C Transmission Problems & Cost | 42RLE | W5A580

The Chrysler 300 / 300M was equipped with the 42RLE, W5A580 (also known as NAG1) or the A606 transmission in earlier models. But they aren’t without their problems though, so let’s look at some of the most common Chrysler 300 / 300M transmission problems, look at cost estimates and figure out what you can do about them.

Need a replacement transmission? Get an estimate for replacement transmissions and local installation. Look up your transmission model by vehicle make and model.

What Transmission Do I Have?

Chrysler 300 / 300M Transmission Models

Chrysler 300 / 300M: 42RLE Transmission
Chrysler 300 / 300C: W5A580 Transmission
Chrysler 300 / 300M: A606 (Early Models)

Chrysler 300 / 300M Transmission Replacement Cost Estimate

Pricing varies by model. To be 100% sure on pricing, have your VIN# handy and use our Get An Estimate feature to look up your transmission by VIN#.

Replacement 42RLE Transmission:

TransmissionStreet Smart TransmissionAutozoneAdvance Auto PartsDealer Retail
42RLE1940173017992482

Replacement W5A580 (NAG1) Transmission:

TransmissionStreet Smart TransmissionAutozoneAdvance Auto PartsDealer Retail
W5A580 / NAG1259045103098n/a

Replacement A606 Transmission:
** Unknown or not available **

What are the DTC codes related to Chrysler 300 / 300M transmission problems?

Trouble CodeDescription
P0700Transmission Control System (MIL Request)
P0706Transmission Range Sensor Circuit Range/Performance
P0710Transmission Fluid Temperature Sensor Circuit
P0711Transmission Fluid Temperature Sensor Circuit Range/Performance
P0712Transmission Fluid Temperature Sensor Circuit Low Input
P0713Transmission Fluid Temperature Sensor Circuit High Input
P0714Transmission Fluid Temperature Sensor Circuit Intermittent P0715
P0717Input/Turbine Speed Sensor Circuit No Signal
P0720Output Speed Sensor Circuit
P0730Incorrect Gear Ratio
P0731Gear 1 Incorrect Ratio
P0732Gear 2 Incorrect Ratio
P0733Gear 3 Incorrect Ratio
P0734Gear 4 Incorrect Ratio
P0735Gear 5 Incorrect Ratio
P0740Torque Converter Clutch Circuit Malfunction
P0742Torque Converter Clutch Circuit Stuck On
P0743Torque Converter Clutch Circuit Electrical
P0748Pressure Control Solenoid 'A' Electrical
P0750Shift Solenoid 'A'
P0751Shift Solenoid 'A' Performance or Stuck Off
P0755Shift Solenoid 'B'
P0760Shift Solenoid 'C'
P0765Shift Solenoid 'D'
P07833-4 Shift
P0841Transmission Fluid Pressure Sensor/Switch “A” Circuit Range/Performance
P0846Transmission Fluid Pressure Sensor/Switch “B” Circuit Range/Performance
P0871Transmission Fluid Pressure Sensor/Switch “C” Circuit Range/Performance
P0880TCM Power Input Signal
P0881TCM Power Input Signal Range/Performance
P0882TCM Power Input Signal Low
P0884TCM Power Input Signal Intermittent
P0888TCM Power Relay Sense Circuit
P0891TCM Power Relay Sense Circuit High
P0897Transmission Fluid Deteriorated

Chrysler 300M / 300C Transmission Recalls

Recall 05V460000 / E14 – Transmission may not hold in the park position
2005 – 2006 Chrysler 300 – 2005 – 2006 Dodge Charger – 2006 Dodge Dakota – 2005 Dodge Durango – 2005 – 2006 Dodge Magnum – 2005 – 2006 Jeep Liberty – 2005 – 2006 Jeep Wrangler
Summary – In November 2005, Chrysler recalled 256,409 vehicles equipped with the 42RLE transmission, because the cup plug that holds the park prawl anchor shaft may not have been properly installed. If the shaft moves out of position, the vehicle may not be able to achieve the Park position.
Consequence – If this occurs and the parking brake is not applied, the vehicle could unexpectedly roll away, causing serious injury and damage.
Remedy – Dealers were instructed to install a bracket to ensure that the 42RLE parking prawl anchor shaft will stay in the proper position. Concerned owners may call Chrysler customer service at 1-800-853-1403 or NHTSA at 1-888-327-4236.

Chrysler 300M / 300C Technical Service Bulletins (TSB)

TSB 21-003-06 – Transmission shudder or buzzing noise due to water contamination
2005 – 2006 Chrysler 300
2005 – 2006 Dodge Magnum
2005 – 2006 Dodge Charger

-Note: This W5A580 transmission TSB is intended to supersede TSB 21-011-05 which included the 2005 Jeep Grand Cherokee

Problem – Owners may experience a shudder vibration and/or a high-frequency buzzing sound. This W5A580/NAG1 transmission problem may be most noticeable during light acceleration where partial application of the torque converter clutch happens in 3rd, 4th, or 5th gears. The reason this happens is because water has gotten past the transmission oil fill tube/dipstick seal. Contaminated transmission fluid can cause the TCC to stick and/or slip.

Solution – If the contaminated transmission fluid has not caused a lot of damage, the transmission and torque converter may be able to be flushed to cure the problem. However, if the contamination is severe, the torque converter will need to be replaced, and the transmission inspected for signs of other damage. The transmission fill tube seal will also need to be upgraded.

Common Chrysler 300 Transmission Problems

Lack of Response
Leaking Fluid
Low Fluid
Burning Smell
Grinding or Shaking
Whining, Clunking or Humming
Refuses to Go Into Gear
Torque Converter Issues
Valve Body Issues
Transmission Noisy in Neutral
Gears Slipping
No 3rd or 4th Gear
No 1st or 2nd Gear
No Reverse
Dragging Clutch
Trouble Codes / Check Engine Light

Can I drive with a transmission problem?

If your Chrysler 300 / 300M can still make it up and down the road, you might say “It’s fine, I’ll just drive it until I can get it fixed”. But that is not always a good idea, depending on the symptoms. You see, there are a lot of (very expensive) moving parts inside of a transmission, and if something isn’t right, continuing to drive with a transmission problem could damage something else.

How often does a Chrysler 300 / 300M transmission need to be replaced?

The overall lifespan of a Chrysler 300 / 300M transmission largely depends on how well it was maintained. Factory design flaws also factor into this equation, along with how/how hard you drive. But on average, we’ve seen the Chrysler 300 / 300M transmission last for between 130,000-180,000 miles. A high quality replacement transmission however, can last considerably longer if all of the factory design flaws have been addressed and the vehicle has been maintained.

How are Chrysler 300 / 300M transmission issues diagnosed?

It is fairly easy to guesstimate what the root cause of your Chrysler 300 / 300M transmission problems might be, but you won’t truly know unless you have the right tools and experience. A good mechanic or transmission repair center will be able to connect your truck to a computer and find out which diagnostic trouble codes (DTC’s) have been stored. Once they know what to look for, they can perform a visual inspection to verify the problem.

How is a Chrysler 300 / 300M transmission replaced?

In order to replace your Chrysler 300 / 300M transmission, the truck has to be lifted from the ground in order to gain access to all of the parts that will need to be unbolted. Then the transmission can be lowered to the ground (typically with a transmission jack), so the new transmission can be installed.

Recommendations for Chrysler 300 / 300M transmission issues?

To save time and get back on the road faster, have your 17-digit VIN# handy and you can get an online quote for a reman Chrysler 300 / 300M transmission here, then find a local shop using our Find a Shop guide to install it for you.

How to Solve Chrysler 300 / 300M Transmission Problems

Solution A: Buy a Used Chrysler 300 / 300M Transmission

The quickest way to fix your transmission problems is to simply buy a used transmission or used transmission. These can be found at most junk yards, and they often come with a 30-90 day warranty. However, there’s no way to determine the actual condition of the internal components, so you could be spending a bunch of money to have the exact same problems. Plus, that warranty only covers the transmission if it’s defective, not the labor costs that you’ll have to pay.

Solution B: Buy a Rebuilt Chrysler 300 / 300M Transmission

Another option would be a rebuilt transmission or rebuilt transmission. A local repair shop will remove your transmission, then install a bunch of new parts during the rebuild. The problem here is, the skills and experience of each transmission rebuilder will vary widely from shop to shop, so you could have problems from something that wasn’t adjusted properly. And the 1-2 year warranty might only cover you at certain transmission repair shops, in a specific geographical area.

Solution C: Buy a Remanufactured Chrysler 300 / 300M Transmission

Many owners depend on their vehicle to commute and get things done. Their gasoline engines are designed to go 100’s of thousands of miles, so it makes sense to invest in a remanufactured transmission.

Need a replacement transmission? Get an estimate for replacement transmissions and local installation. Look up your transmission model by vehicle make and model.

What Transmission Do I Have?

What Problem Does Your Chrysler 300 / 300M Have?

Let us know the year, mileage and problem you’re having as well as any trouble (OBD) codes you’ve found. If you’ve been given a quote or paid for a repair, we’d like to hear about that too!

12
Leave a Comment

Bill

The engine came on took it to auto zone the codes po 700 came up po841 871 1776 700 703

Ej

What’s a cheap way i can get my transmission fix

John

Have a 2007 300 hemi. Car won’t come out of park

Lorraine

I have a 2005 300c working fine one day next can put gear shift in reverse and drive and it will not go. No codes.

Paul

Any progress on this. Mine does a similar thing?

Jean-Yves Denis

j’ai un code p0734 la transmission a pas de lock up en partant avec le lock up est embarqué et la transmission revient en 3ie vitesse et over drive

Malik

p0700 and p0730 code on chrysler

israel

sorry drops from 2nd to 1st in automatic and makes a shutter sound then goes back to second gear if I shift it myself its ok does not drop back to a lower gear

israel

drops to a lower gear when driven in stander mode its ok cause im shifting it in automatic it does not know to stay in that gear uselly In in first or second gear

huck

chrysler 300 error code 740 sometimes will not change 1st gear . turn car off then it will work also humming now

Ej

How did u fix your problem im haven the same problem

Steve

2000 300M 203,000. No reverse P0736, P0700.
